LOMA PRIETA 900MHZ REPEATER
FREQUENCIES
OUTPUT 927.9000 MHZ
INPUT 902.0375 MHZ
ANALOG DPL 411
P25 NAC 293
Allstar Node 41306
Located at Loma Prieta Site 3 overlooking San Jose, Santa Cruz, and Monterey @ 3900'
The Loma Prieta 900MHZ repeater is a Motorola Quantar with a output of 100 watts into a Andrew Vertical antenna 60 feet up the tower. The antenna has about 9db of gain and is fed with 7/8" Andrew hardline.
The Controller is a Arcom RC-210 that has three ports and a real time clock installed.
The Duplexer is a Band pass / Notch design.
The Duplexer is foillowed by a Bandpass filter then a GaAsFET Amplifier.
Port 2 has a VHF Maxtrac Transciever in Remote Base config.
Port 3 has a Rasberry Pi with URI for the Allstar Node.
Coverage
This Repeaters coverage includes Santa Clara County, Santa Cruz County, Monterey County, Alameda County, San Francisco County, San Mateo County, and parts of Fresno County, Contra Costa County, San Joaquin County, San Benito County, and Napa County.
